PT-25.6V9Ah
Product Description
Product Features
FAQ
Product Tags
Key Takeaways
- 25.6V 9Ah (230.4Wh) LiFePO₄ ups battery pack with 8S · 3 parallel strings configuration.
- 45A continuous discharge and 60 (5 s) peak/protection current.
- 11-year design life for long service intervals.
- 181 × 77 × 167 mm and 2.9 kg, IP54 rated.
- UL1973 / IEC62619 / UN38.3 compliance.
Construction & BMS
The pack is built in a lead-acid-compatible case with lead-acid style terminals. The integrated BMS provides over-charge, over-discharge, over-current, short-circuit and over-temperature protection, with cell balancing for long string life.
- Lead-acid-compatible case — mechanical protection and mounting
- lead-acid style terminals — low-resistance connection
- Integrated BMS with cell balancing
- Batch-level cell traceability
Electrical Performance
25.6V nominal and 9Ah (230.4Wh) give predictable runtime for ups systems. Continuous discharge is 45A and maximum charge is 9A.
- 25.6V nominal / 9Ah
- 45A continuous discharge
- 9A maximum charge
- 8S · 3 parallel strings configuration
Reliability & Temperature
11-year design life and a charge window of 0 to +45 °C with discharge from −20 to +60 °C make the pack suitable for continuous duty. UL1973 / IEC62619 / UN38.3 compliance supports global deployment.
- 11-year design life
- Charge 0 to +45 °C
- Discharge −20 to +60 °C
- UL1973 / IEC62619 / UN38.3
Technical Specifications
| Mechanical | |
|---|---|
| Case material | Lead-acid-compatible case |
| Dimensions | 181 × 77 × 167 mm |
| Weight | 2.9 kg |
| Terminals | lead-acid style terminals |
| IP rating | IP54 |
| Electrical | |
|---|---|
| Model | PT-25.6V9Ah |
| Chemistry | LiFePO₄ (LFP) |
| Nominal voltage | 25.6 V |
| Nominal capacity | 9 Ah |
| Energy | 230.4 Wh |
| Configuration | 8S · 3 parallel strings |
| Max charge current | 9 A |
| Continuous discharge | 45 A |
| Peak / protection | 60 (5 s) A |
| Charge temperature | 0 to +45 °C |
| Discharge temperature | −20 to +60 °C |
| Service life | 11-year design life |
| Compliance | UL1973 / IEC62619 / UN38.3 |
Application Scenarios
One ups battery pack platform for ups systems, telecom, security systems.
Storage & Reliability
Store the pack at −20 to +45 °C in a dry environment, away from direct sunlight. Avoid deep discharge during long storage and recharge every three months.
